Professional Highly Directional Camera Shotgun Mic SYNCO D30
The SYNCO Mic-D30 is a professional highly directional camera shotgun mic launched to be an "audio technician". It features sophisticated microphone amplifier to boost the sound signals while maintaining low self-noise, provides transparent sound performance and flexible functionality diversification, and works very well with cameras, camcorders, smartphones, recorders, laptops, tablets, and bodypack transmitters.
Want to see D30 shotgun mic reviews, check SYNCO camera mic D30 - Flexibility in a variety of situations
Stepless Analog Gain Knob
The D30 DSLR camera shotgun mic provides a stepless analog gain knob, adjustable from -10dB to 15dB non-linearly. It concurrently controls the microphone amplifier and headphone amplifier. Either input signals or output signals can be adjusted to a proper level for distortionless sound.
Doubled Sound Track Protection
The embedded overdrive protection system protects the sound recording from distortion when it reaches the maximum sound pressure level of 124 dB SPL. The safety channel ensures the audio won't be broken or lost at the peak of SPL by 10dB attenuation.
Real-time Audio Monitoring System
A 3.5mm TRS headphone monitoring jack is used to real-time check what's got in the soundtrack ultimately. The shotgun mic for video camera is paired with those headphones under 55 Ohm impedance to monitor the audio for energy saving.
Patented Type-C Interface
The SYNCO D30 carries a Type-C interface with a utility model patent. It supports analog signal output. Type-C interface retains much more audio details than the usual 3.5mm port, delivering high-quality sound for users.
75Hz/150Hz Low Cut Filter
With ultra-low-noise electronics, this DSLR microphone generates little inherent noise. The optional 75Hz/150Hz low cut filter further purifies the sound, removing most of low-frequency noises caused by airflow, shake, electrical current, and traffic.
Acoustic Noise Canceling Array
The Ox horn-like texture, namely Acoustic Noise Canceling Array (ANCA), enables the camera shotgun mic D30 to better process sound waves, reduce off-axis noise, and focus on capturing the audio in front of the capsule, along with a supercardioid condenser and an interference tube. The output is clear, crisp, and natural sound.
SYNCO Mic-D30 is a professional highly directional camera shotgun mic launched to be an “audio technician”.
Stepless Analog Gain Knob
Mic-D30 video camera shotgun mic provides a stepless analog gain knob, adjustable from -10dB to 15dB non-linearly.
Ultra-flat Frequency Response
The frequency response range is 20Hz—20KHz. With ultra-flat frequency response, Mic-D2 outputs all the frequencies that we can hear at once and produces accurate natural sound from the source.
Doubled Sound Track Protection
The overdrive protection and safety channel are combined to ensure the sound from distortion, damage and drop.
Real-time Audio Monitoring System
A 3.5mm TRS headphone monitoring jack is used to real-time check what’s got in the soundtrack ultimately.
Patented Type-C Interface
It supports analog signal output and retains much more audio details over usual 3.5mm port.
75Hz/150Hz Low Cut Filter
It purifies the sound and removes most of low-frequency noises caused by airflow, shake, electrical current, and traffic.
Acoustic Noise Canceling Array
Ox horn like textured D30 is allowed to better process sound wave and focus on the audio in front of the capsule.
Specifications
| Transducer | Back Electret Condenser |
|---|---|
| Polar Pattern | Super Cardioid |
| Frequency Response | 20Hz to 20KHz |
| Dynamic Range | 119dB SPL (A-weight per IEC651) |
| Signal/Noise | 82dB（1KHz at 1Pa）(A-weight per IEC651) |
| Sensitivity | -24dB±2dB (1dB=1V/Pa at 1KHz) |
| Max. Input SPL | 124dB SPL |
| Output Impedance | 16Ω (Headphone) 300Ω±20% (at 1KHz) (Line out) |
| Low Frequency Roll-off | 75Hz/150Hz |
| Output Interface | Type-C to 3.5mm |
| Dimensions | Φ21.5×214.5mm |
| Weight | 85g |
Specifications
| Transducer | Back Electret Condenser |
|---|---|
| Polar Pattern | Super Cardioid |
| Frequency Response | 20Hz to 20KHz |
| Dynamic Range | 119dB SPL (A-weight per IEC651) |
| Signal/Noise | 82dB（1KHz at 1Pa）(A-weight per IEC651) |
| Sensitivity | -24dB±2dB (1dB=1V/Pa at 1KHz) |
| Max. Input SPL | 124dB SPL |
| Output Impedance | 16Ω (Headphone) 300Ω±20% (at 1KHz) (Line out) |
| Low Frequency Roll-off | 75Hz/150Hz |
| Output Interface | Type-C to 3.5mm |
| Dimensions | Φ21.5×214.5mm |
| Weight | 85g |
